Temperature Loading of a Tapered Cylinder
Temperature Loading of a Tapered Cylinder
![Temperature Loading of a Tapered Cylinder](/model-images/temperature_loading1.jpg)
This validation test case models temperature loading of a tapered hollow thick cylinder with a spherical bottom flange section. The solid object is assumed to be clamped vertically, but allowed to expand horizontally due to a linear temperature gradient. The stress in the z-direction at the bottom inner point is …
Cooling Effect of Adding Fins
Cooling Effect of Adding Fins
![Cooling Effect of Adding Fins](/model-images/heat_transfer5.jpg)
This example models heated steam at a constant temperature of 120 C flowing through a aluminium pipe with 3 cm diameter. Heat loss to the surrounding cool air (at 25 C and heat transfer coefficient of h = 60 W/m2 C) is computed for a plain pipe, and also a pipe where 200 cooling fins per meter has been added. The …
Multi-Simulation Heat Exchanger
Multi-Simulation Heat Exchanger
![Multi-Simulation Heat Exchanger](/model-images/multi_simulation1.jpg)
This tutorial model illustrates how one can couple the OpenFOAM CFD solver with the FEATool Multiphysics FEA solver. In the model a stream of cool air is heated while flowing through a tube and fin heat exchanger. Due to several symmetry planes only a small section of the full heat exchanger geometry actually needs to …
Space-Time Transformation of Heat Conduction
Space-Time Transformation of Heat Conduction
![Space-Time Transformation of Heat Conduction](/model-images/heat_transfer4.jpg)
This example considers transient heat diffusion in a solid 1 m rod where one end is kept at T = 25 degrees and the other subject to constant heat flux q_n = 1. This one-dimensional time dependent problem is transformed to a static two dimensional one. The computed results can both be compared with the analytical …
Thermal Bridge
Thermal Bridge
![Thermal Bridge](/model-images/thermal_bridge1.jpg)
This is a benchmark test case for modeling the steady-state temperature distribution in a thermal bridge in building construction. The model consists of a 6 mm concrete slab subjected to an outside temperature of 0 °C and heat loss due to convection. The inside features a 4 cm layer of air enclosed within a 1.5 mm …
Orthotropic Heat Conduction
Orthotropic Heat Conduction
![Orthotropic Heat Conduction](/model-images/orthotropic_heat_conduction1.jpg)
This is an example of modeling anisotropic heat conduction in an orthotropic material where a heated solid bar suddenly is cooled by submerging it in a cool fluid. The material features different thermal conductivities in the x and y-directions which is accounted for by modifying the diffusion term in the heat transfer …
Simulation of Heating to Promote Drug Mixing in the Eye
Simulation of Heating to Promote Drug Mixing in the Eye
![Simulation of Heating to Promote Drug Mixing in the Eye](/model-images/featool-multiphysics-ocular-mixing-simulation.jpg)
The leading cause of central vision loss in the developed world is from age-related macular degeneration (AMD). Although certain types of AMD can generally be managed with injections of anti-VEGF agents, the treatment is sometimes ineffective. The linked study examines how this type of treatment potentially can be …
